Translation module AS510/1
incremental, interface, resolution 5 μm
- Parameters adjustable via DIP switches
- Resolution up to 5 μm
- Reference signal with intervals of 5 mm
- Works with sensor MS500
Technical drawing
Technical Specifications
More information
pin assignment
|
Signal |
PIN |
|
A |
1 |
|
A/ |
2 |
|
"GND (for output signal) " |
3 |
|
B |
4 |
|
B/ |
5 |
|
0 |
6 |
|
0/ |
7 |
|
+UB |
8 |
|
GND (for supply) |
9 |
Purchase order
Product configuration
Feature
Select specifications
Enhancement
Operating voltage
4
Scope of delivery
- AS510/1
- User information
