Analog position indicator S80/1
Compatible with many common handwheels
- analog position indicator
- Measured value acquisition based on the gravity principle
- High stability thanks to doubly supported pointer shaft
- Very robust, glass-fiber reinforced plastic housing
- Wide range of gear ratios
- Special scales, also for small numbers of pieces
- Dustproof, oil-filled or waterproof versions
Ben
King
Inside Sales
Cary
Mulvany
Manager Business Unit Changeover Solutions
Technical drawing
Technical Specifications
Mechanical data
Feature
Technical Specifications
Enhancement
Weight
0.1
kg
N, W design
0.2
kg
P design
Housing
reinforced plastic
Purchase order
Product configuration
Feature
Select specifications
Enhancement
Select your specifications:
version
N
Gear ratio
1
Sense of rotation
i
Pointer
1
covering glass
S
zero position
ON
scale
N…
related to the transformation ratio
customer-specific, no VK for first production
multi-color scale
C1
Scope of delivery
- S80/1
