Electronic position indicator AP10S
With bus interface, for direct linear length measurement
Absolute position display with communication interface for linear or slide adjustment intuitively guides the operator to the correct machine setting when changing products or changing formats. Readability is optimized for intuitive user prompting: The backlit display clearly shows the setpoint and actual value, and the two LEDs clearly indicate the direction in which the adjustment must be made. The IO link interface enables easy and reliable integration into modular machines.
- Electronic position indicator with plug connection for magnetic sensor
- Optimally readable backlit display
- Two-line LCD for target and actual values
- Reset, incremental measurement, offset via keyboard
- Integrated RS485 interface, CAN bus or IO-Link as an option
- Display accuracy up to 0.01 mm
- Absolute function via internal backup
- User guidance via bicolor status LEDs
- IP53 protection class, IP65 as an option
- Industry 4.0 ready
Ben
King
Inside Sales
Cary
Mulvany
Manager Business Unit Changeover Solutions
Technical drawing
Technical Specifications
Mechanical data
Electrical data
System data
Ambient conditions
Feature
Technical Specifications
Enhancement
Weight
~0.11
kg
Housing
reinforced plastic
plug thread, nickel-plated brass/cover, metal ground connection
Color
black, RAL 9005
Feature
Technical Specifications
Enhancement
Operating voltage
24 V DC ±20 %
Current consumption
~30
mA
when operated with LEDs additionally ~3 mA per LED
Power input
~0.72
VA
max. power supply of the power supply unit used: 100 VA. The power supply used corresponds to SELV/Limited Energy (IEC 61010-1) or SELV/LPS (IEC 60950-1) or Class 2 (UL 1310).
Battery service life
~8
Year(s)
Parameter storage
105 cycles
also applies to calibration operations
Display/display range
6-digit LCD 14-segment, ~8 mm high
decimal points, 2 rows, special characters (backlit LED red/white)
Special character
cw arrow, ccw arrow, incremental measurement, battery
Status display
2x two-color LED (red/green)
position status, configurable
Keys
incremental measurement function, parameterizing, resetting
Interface
RS485, CANopen, IO-Link
no galvanic isolation
Type of connection
2x M8 plug connectors (A-coded)
4-pin, 1x socket, 1x pin (RS485, CANopen)
1x M8-plug connector (A-coded)
4-pin, 1x pin (IO-Link)
1x M8-plug connector (A-coded)
6-pole, 1x socket (sensor)
grounding via flat male tab 6.3 mm or terminal lug
Feature
Technical Specifications
Enhancement
Scanning
external sensor
Resolution
720
Increments/revolution
displayed value/rotation freely configurable (use with GS04)
0.01
mm
use with MS500H
System accuracy
±35
µm
use with MS500H
Measuring range
±20971
m
use with MS500H
≤233016
rotation(s)
use with GS04
Approval
UL
UL 61010-1, File No. E503367
Feature
Technical Specifications
Enhancement
Ambient temperature
0 … 60 °C
Storage temperature
-20 … 80 °C
Relative humidity
condensation inadmissible
EMC
EN 61326-1
Industry immunity requirement, class B emission limit, shielded line required
Safety regulations
DIN EN 61010-1 (VDE 0411-1), UL 61010-1
Limited power supply according to DIN EN 61010-1 Section 9.4.
Protection category
IP53
EN 60529, with mating connectors (degree of protection not tested by UL)
IP65
EN 60529, with mating connectors (degree of protection not tested by UL)
Shock resistance
500 m/s2, 11 ms
EN 60068-2-27
Vibration resistance
<100 m/s2, 5 … 150 Hz
EN 60068-2-6
More information
pin assignment
Interfaces
|
RS485 |
CAN-Bus |
IO-Link |
PIN |
|
TxRx-/DÜB |
CANL |
L+ (+UB) |
1 |
|
TxRx+/DÜA |
CANH |
nc |
2 |
|
+UB |
+UB |
L- (GND) |
3 |
|
GND |
GND |
C/Q |
4 |
Industry 4.0
In most cases, data exchange with the position indicators is limited to the exchange of process data. In addition to the process data, intelligent displays provide additional information that can be evaluated for condition monitoring up to predictive maintenance:
|
Process data |
Smart Value |
Smart Function |
|
Actual position |
Battery voltage |
Battery change planning |
|
"Target position " |
Presence, distance, alignment sensor |
Counting error |
Purchase order
Product configuration
Feature
Select specifications
Enhancement
Select your specifications:
interface/
protocol
CAN
Protection category
IP53
Sight window
SF
impact protection
Accessories
Comparable products
Scope of delivery
- AP10S
- Documentation on CD
- Installation Instructions
